Homein hermetically sealed air tight double automatic sliding door for surgery room

Hermetically sealed airtight double automatic sliding doors made of galvanized steel are specially designed for critical environments such as operating theatres, isolation rooms, and cleanroom zones in hospitals. These doors ensure controlled air pressure by forming a complete airtight seal when closed, preventing the ingress or egress of airborne contaminants.

The door panels and frame are constructed from durable galvanized steel, offering excellent resistance to corrosion, impact, and cleaning chemicals. The double sliding configuration provides a wide clear opening, ideal for moving medical equipment and patient beds, while the hermetic sealing system ensures minimal air leakage to maintain sterility and air pressure differentials.

Equipped with an automatic operator, these doors offer hands-free operation through sensors or switches, reducing contamination risk and improving workflow efficiency in sterile areas.

Features

• Hermetically Sealed System
  Specialized sealing mechanism ensures the door moves downward and inward upon closing to press tightly against the frame and floor, achieving high airtightness (typically Class 3 per DIN EN 12207).

• Galvanized Steel Construction
  Door leaf and frame are made from high-quality galvanized steel with a smooth, powder-coated or painted finish, offering high strength, corrosion resistance, and easy maintenance.

• Double Sliding Door Configuration
  Two-panel design provides a large clear opening width, facilitating the movement of surgical equipment and hospital beds.

• Automatic Operation
  Integrated with a microprocessor-controlled operator system for reliable, silent operation with adjustable speed, hold-open time, and soft-close features.

• Touchless Activation
  Compatible with elbow switches, motion detectors, foot sensors, or access control systems to ensure hands-free operation in sterile zones.

• Antibacterial and Cleanable Surface
  Galvanized steel surfaces can be coated with antibacterial powder paint or film laminate, making them resistant to hospital-grade cleaning agents.

• Optional Vision Panel
  Flush-mounted lead-free safety glass or double-glazed panel allows visual monitoring while maintaining the door’s airtight integrity.

• High Airtightness Performance
  Minimizes air leakage and supports the maintenance of positive or negative pressure environments in operating rooms.

• Easy Cleaning and Maintenance
  Smooth panel design with hidden hardware and sealed joints minimizes dirt accumulation and allows for thorough disinfection.

• Safety Features
  Includes obstacle detection sensors, emergency open/close function, and battery backup system to ensure safe operation during power failures.

• Standards Compliance
  Designed to meet hospital and cleanroom standards including ISO 14644, HTM 03-01, and local fire and safety codes.
