Homein commerical grey UL fire proof glazed steel fireproof push bar emergency

MOQ: 1PCS Custom Size Fast Delivery Quality Assurance

Item NO.:
PBM14
Door Type.:
Material
Galvanized steel
Application:
Color:
Grey
Design:
Style:
Lead Time:
33 days
Suppliy ability:
Place of Origin:
Yongkang city, China
Certificate:
Ref Price:
350 USD

Fire rated Up to 3 hours
Comply to UL10c,BS976,EN1634 safety codes and regulations
Quality galvanzied steel material
Light-weight and Environmentally friendly mineral core materials
Equipped with fireproof certified hinge and push bar and self-close Mechanism
Weld frame and knock-down frame for choose
Multipble anchor for differnet wall installation

Door Size	Door Type	Frame width	Frame height	Leaf width	Leaf height	Open width	Open height

Door material	0.8~1.2mm Galvanized steel
Frame material	1.2~1.8mm Galvanized steel
Door core	Honeycomb; PU; mineral core; acoustic wool
Finish	Poweder coating
Leaf thick	Std:45mm (customizable)
Width	Std:3ft (customizable Max: 1250mm single leaf)
Height	Std:7ft (customizable Max: 4000mm)
Hardware	Push bar & trim; Hinge; Closer
STC	Max STC56
Fire rate	Max 120min

Right hand interior

Stand at outside; hinge at right hand; lock at left hand, door swing to inside

Left hand interior

Stand at outside; hinge at left hand; lock at right hand, door swing to inside

Right hand outside

Stand at outside; hinge at right hand; lock at left hand, door swing to outside

Left hand outside

Stand at outside; hinge at left hand; lock at right hand, door swing to outside

Right hand active interior

Stand at outside; right leaf active; lock at righ leaf, door swing to inside

Left hand active interior

Stand at outside; left leaf active; lock at left leaf, door swing to inside

Right hand active outside

Stand at outside; right leaf active; lock at right leaf, door swing to outside

Left hand active outside

Stand at outside; left leaf active; lock at left leaf, door swing to outside

Door Slabs Construction (Optional)

Isolation and Fireproof Exit door

50mm Thk; 1.0 galvanized steel panel; 1.5mm galvanzied steel hollow frame, Fireproof mineral core; Graphite smoke seal; Fire rate 2 hours, isolation 1 hour

Acoustic and Fireproof Exit door

90mm Thk; 1.0 galvanized steel panel; 1.5mm galvanzied steel hollow frame, fireproof and soundproof core; smoke seal+acoustic seal; Fire rate 2 hour, STC56

Fireproof Exit door

45mm or 50mm Thk; 1.0 galvanized steel panel; 1.5mm galvanzied steel hollow frame, Fireproof honeycomb paper core; smoke seal all round; Fire rate 3 hours

Door Frame Type (Optional)

Welded door frame

1.2-1.8mm Galvanized steel frame; welded frame;fire rate up to 3 hours

Knock-down door frame A

1.2-1.8mm Galvanized steel frame; Knock-down frame; fire rate up to 3 hours

Knock-down door frame B

1.2-1.8mm Galvanized steel frame; Knock-down frame;fire rate up to 3 hours

Double rebate door frame

1.2-1.8mm Galvanized steel frame; welded frame;fire rate up to 3 hours

Double egress door frame

1.2-1.8mm Galvanized steel frame; welded frame; use for acoustic door, stc grade up to stc56

Standard Door Hardware

Push bar A (Standard)

SUS304 or Galvanized steel material; Fire rate up to 3 hours; with outer trim in SUS304 or zinc alloy

Push bar B

Galvanized steel material; with outer trim

Push bar C

SUS304 material; with outer trim

Hydraulic closer

Aluminum alloy; adjustable speed; Fire rate up to 1.5hours

Butt Hinge

SUS304 stainless steel; Size in 4''*4''*3mm or 4''*3''*3mm; 2BB; SUS304 screw; ; Fire rate up to 3hours

Acoustic seal

12*12mm acoustic seal; STC 33Db; Durable rubber; self-stick;

Optional Architrave

Optional Louver

Glass lite (Optional)

Double glass

Isolation Double glass 20~40mm thick, standard is 25mm,Fire-resistant up to 90 minutes

NFR Frosted glass

5mm~12mm optional, standard is 5mm

NFR Clear glass

5mm~12mm optional, standard is 5mm

FR Wired glass

90min fire rated; Classified and labeled

Schott FR clear glass

2 hour fire rated; Classified and labeled
