Products
Item NO.:
CMD18Door Type.:
Single door, swing doorMaterial
Galvanized steelApplication:
Commerical buildingColor:
GreyDesign:
Embossed 6 PanelStyle:
ClassicLead Time:
20 daysSuppliy ability:
1500 sets per monthPlace of Origin:
Yongkang city, ChinaCertificate:
UL BS476Ref Price:
200 USD| Door Size | Door Type | Frame width | Frame height | Leaf width | Leaf height | Open width | Open height |
|---|---|---|---|---|---|---|---|
| 3*7ft | Single | 915 | 2135 | 2045 | 2080 | 800 | 2088 |
| 3*8ft | Single | 915 | 2440 | 2350 | 2385 | 800 | 2393 |
| 4*8ft | Single | 1220 | 2440 | 2350 | 2385 | 1105 | 2393 |
| Door material | 0.8~1.2mm Galvanized steel |
|---|---|
| Frame material | 1.2~1.8mm Galvanized steel |
| Door core | Honeycomb; PU; mineral core; acoustic wool |
| Finish | Poweder coating |
| Leaf thick | Std:45mm (customizable) |
| Width | Std:3ft (customizable Max: 1250mm single leaf) |
| Height | Std:7ft (customizable Max: 4000mm) |
| Hardware | Lock; Hinge; Closer |
| STC | Max STC56 |
| Fire rate | Max 120min |
Stand at outside; hinge at right hand; lock at left hand, door swing to inside
Stand at outside; hinge at left hand; lock at right hand, door swing to inside
Stand at outside; hinge at right hand; lock at left hand, door swing to outside
Stand at outside; hinge at left hand; lock at right hand, door swing to outside
Door Slabs Construction (Optional)
45mm or 50mm Thk; 0.8 or 1.0 galvanized steel panel; Honeycomb paper core
45mm or 50mm Thk; 0.8 or 1.0 galvanized steel panel; Aluminum Honeycomb paper core
45mm or 50mm Thk; 0.8 or 1.0 galvanized steel panel; Fireproof mineral core; smoke seal all round
60mm or 70mm Thk; 0.8 or 1.0 galvanized steel panel; Acoustic core; acoustic seal all round
Door Frame Type (Optional)
1.2-1.8mm Galvanized steel frame; welded frame;fire rate up to 3 hours
1.2-1.8mm Galvanized steel frame; Knock-down frame; fire rate up to 3 hours
1.2-1.8mm Galvanized steel frame; Knock-down frame;fire rate up to 3 hours
1.2-1.8mm Galvanized steel frame; welded frame;fire rate up to 3 hours
1.2-1.8mm Galvanized steel frame; welded frame; use for acoustic door, stc grade up to stc56
Standard Door Hardware
SUS304 handle; SUS304 forend; SUS latch & deadbolt; brass cylinder & key; SUS304 screw; Fire rate up to 3hours
View More >>>
SUS304 handle; SUS304 forend; SUS latch & deadbolt; brass cylinder & key; SUS304 screw; Fire rate up to 2hours
View More >>>
SUS304 stainless steel; Size in 4''*4''*3mm or 4''*3''*3mm; 2BB; SUS304 screw; ; Fire rate up to 3hours
View More >>>Popular Solid color
Read More Color >>>
Pre：Commerical 1 panel embossed steel clad fireproof metal door
Next：commercial fireproof 4 panel embossed metal steel door
